Strong plastic shredder characteristics:
1.The strong plastic shredder has wide application and used for shredding different kinds of plastic materials,different shape plastic product.
2.Mature manufacture techniques,integrating manufacture inbox body,knife shelves and other important parts to ensure a perfect match.
3.Good designing structure,convenient operation,energy-saving and durable,high efficient and economical.
4.Several security protection devices to ensure safe operation.
5.Input sieve with double-deck soundproof design to mitigate noise.
6.Machines in this series are stable,low noise,powder-pollution-free during the operation.The granules are evently produced and in good performance.No overheating during operation and long use life.
7.The plastic shredder adopt sealed bearings to ensure the long-term perfect operation of bearig.The cutter shape is reasonalbe to render the products into even granules.The cutter frame is processed via heat treatment and strong.
- Product Detail
- Inquiry
Technical parameters: Model Diameter of Crushing Chamber(mm) Crushing capacity (kg/h) Motor Power (kw) Fixing Cutter (pcs) Flexible Cutter (pcs) Mechanical Dimension (mm) Weight (kg) TLE2520 250x200 40-60 2 2 3 1020x670x1090 170 TLE3126 310x240 50-80 5.5 2 3 1150x720x1220 235 TLE4132 410x320 70-150 7.5 2 6 1080x860x1370 430 TLE5132 510x320 100-200 11 2 6 1200x990x1550 550 TLE6033 600x330 150-250 15 2 6 1290x1130x1670 650 TLE6246 620x460 200-500 22 2 6 1600x1240x1970 900 TLE7246 720x460 250-600 22 2 6 1600x1340x1970 1100 TLE8146 810x460 300-700 30 4 6/9 1650x1450x2080 1600 TLE8150 810x500 300-800 30 4 9 1650x1450x2080 1600 TLE8156 810x560 300-900 37 4 6/9 2000x1500x2250 1900 TLE8256 820x560 300-900 37 4 9 1800x1480x2330 1900 TLE1065 1020x650 350-1000 45 4 12 1960x1750x2660 2300 TLE1083 1030x830 600-1200 55 4 15 2900x2120x3420 3700 TLE1283 1230x830 650-1300 75 4 9/18 3010x2320x3700 4500 TLE1510 1530x1000 1000-2000 75 6/10 9/15 3010x2550x3700 6000
